ASY-B Rotogravure Printing Machine

0086-577-58910222
DESCRIPTION



Product ID:ASY-B
Sort:Printing machine series
Name:ASY-B Rotogravure Printing machine
ASY-B Rotogravure Printing machine

Application:
This machine is suitable for printing roll plastic film, non-woven cloth, thin leather, paper, aluminum foil, cloth and various soft packages with excellent performance and it is a kind of ideal printing equipment for wine box, shoe bag, milk film and vest bag.

Performance and Features:
1. The latest improved gear box, 360°non-stopping registration device.
2. Movable type doctor blade, transverse reciprocating motion.
3. Far-infrared heating tube drying system can keep dry at a speed of 60m/min.
4. Unwinding and traction adopts magnetic powder brake to make material moving more stable.
5. Rewinding and traction adopt magnetic powder clutch to make color register accurate and rolling end face more neat and smooth.
6. Current output type temperature control system makes heating quicker and electricity saving.
7. Turnover double-station unwinding and rewinding mechanism, receiving and replacing material without stopping the machine.
8. Obverse and reverse side once-through continuous printing.
9. Double-oven drying system and large plate device can print the pattern with 1200mm in girth

Main Technical Variables:

Type ASY-B-6600 ASY-B-6800 ASY-B-61000
Effective Printing Width 600mm 800mm 1000mm
Max.Width of Web 620mm 820mm 1020mm
Max. Printing Speed 10~60m/min 10~60m/min 10~60m/min
Max. Diameter of Unwind/Rewind ф600mm ф600mm ф600mm
Diameter of Printing Cylinde ф70~ф390mm ф70~ф390mm ф70~ф390mm
<span
