Home-Product-Slitting machine

LFQ-A Series Vertical Automatic Slitting & Rewinding Machine

0086-577-58910222
DESCRIPTION

This machine is suitable for slitting and rewinding such various roll materials as BOPP, PET, CPP, CPE, PVC, aluminum foil and paper, etc. and can cut edge, separate and cut material according to different requirements during production.





Type LFQ-700A LFQ-1100A LFQ-1300A
Max.Width of Mother Roll 700mm 1000mm 1300mm
MAX.Diameter of Mother Roll Φ600mm Φ600mm Φ600mm
Width of Final Roll 30-600mm 30-600mm 30-600mm
Slitting and Rewinging Speed 5-160m/min 5-160m/min 5-160m/min
Tolerance of EPC <±0.5mm <±0.5mm <±0.5mm
Total Power 2.7kw 3.5kw 3.5kw
Weight of Machine 1200kg 1500kg 1800kg
Overall Dimension 2000*1100*1400mm 2300*1100*1400mm 2600*1100*1400mm




Inquiry

If you have any enquiry about quotation or cooperation,please feel free to email us at ray@sanbi.comor use the following enquiry form. Our sales representative will contact you soon. Thank you for your interest in our products.
