Home-Product-Bag Making Machine

TPM- 600/800Zipper Bag With Attachment

0086-577-58910222
DESCRIPTION

Performance and Characteristics:
1.This machine uses fully automatic servo motor with computer digital function to control length, it is easy for operation. The produced one is very tight and fast at the seals, it apparently shows a good quality.
2.Flow process of production is from rolled material through automatic edge alignment, edge trimming, strip piercing, laminating, ultrasonic compressive embossing, photo cell sensing, hole punching, thermo cutting off and ends with automatic counting, all of the operations are fully automatic.
3.This machine equips automatic stop equipment, it will work to stop the machine when it is running out of material supply or when photo cell is out of order or when temperature is losing down and below the minimum required.

Main Technical Variables



Machine model TPM-600 TPM-800
Material LDPE-PP-PPE LDPE-PP-PPE
Capacity 50~150 (Cycle/min) 50~130 (Cycle/min)
Cutting width 100~500 mm 120~600 mm
Cutting length 120~600 mm 150~800 mm
Thickness of film 0.04~0.15 mm 0.04~0.15 mm
Film annulus diameter φ500*1200 mm φ500*1600 mm
Step motor 1kw 1kw
Transducer motor 1.5kw 2.2kw
Heater 3kw 3.5kw
Food-out motor 0.25kw 0.37kw
Ultrasonic 1set 1set
Conveying electrical 0.55kw 0.75kw
Food film motor 0.55kw 0.75kw
Sealing capacity 10-30m/min 10-30m/min
Cooling 0.37kw 0.37kw
Power 15kw 17kw
Overall dimension (L*W*H)mm 8500*1800*1800 8650*1900*1800
Voltage 50Hz 220v 50Hz 220v
Press empty machine 1900*1850*1700 2100*1850*1700
Packing dimension (L*W*H)mm 1700*1500*1900 1900*1500*1900
